Disparity through time plot using lattice

Plots points on 2-D surfaces within a a 3-D framework. See lattice::wireframe() and lattice::panel.cloud() for customization options.

Usage

disparity_through_time(
  x,
  data,
  groups,
  pch = 16,
  col.point = c("blue"),
  scales = list(arrows = FALSE, distance = 1, col = "black", z = list(rot = 90)),
  colorkey = FALSE,
  screen = list(z = 90, x = 70, y = 180),
  aspect = c(1.5, 4),
  drape = TRUE,
  col.regions = c("white"),
  alpha.regions = c(1),
  perspective = FALSE,
  R.mat = matrix(c(1, 1, 0, 0, 0, 1, 0, 0, 0, 0, 1, 0, 0, 0, 0, 1), 4, 4),
  par.settings = list(axis.line = list(col = "transparent"), layout.heights =
    list(top.padding = 0, main.key.padding = 0, key.axis.padding = 0, axis.xlab.padding =
    0, xlab.key.padding = 0, key.sub.padding = 0, bottom.padding = 0), layout.widths =
    list(left.padding = 0, key.ylab.padding = 0, ylab.axis.padding = 0, axis.key.padding
    = 0, right.padding = 0)),
  lattice.options = list(axis.padding = list(factor = 0)),
  ...
)

Arguments

x

a formula (most likely of the form z ~ x * y)

data

a data frame in which variables in the formula are to be evaluated

groups

a variable in data to be used as a grouping variable (this is probably the z variable)

pch

the point type

col.point

color(s) for points on surfaces

scales

a list specifying how the axes are drawn (see lattice::xyplot() for details)

colorkey

logical, should a legend be drawn (or a list describing the legend; see lattice::levelplot() for details)

screen

a list of the rotations that should be applied to each axis

aspect

a numeric vector of length 2, giving the relative aspects of the y-size/x-size and z-size/x-size of the enclosing cube

drape

logical, whether the surfaces should be colored based on col.regions and alpha.regions

col.regions

color(s) for surfaces

alpha.regions

alpha value(s) for surfaces

perspective

logical, whether to plot a perspective view

R.mat

a transformational matrix that is applied to the orientation of the axes

par.settings

plotting settings (see lattice::trellis.par.set())

lattice.options

lattice settings (see lattice::lattice.options())

...

Other arguments passed to lattice::wireframe()

Value

An object of class "trellis", as output by lattice::wireframe().

Examples

g <- data.frame(
  x = runif(100, 0, 60), y = runif(100, 0, 10),
  z = factor(rep(periods$name[1:5], each = 20),
    levels = periods$name[1:5]
  )
)
disparity_through_time(z ~ x * y,
  data = g, groups = z, aspect = c(1.5, 2),
  xlim = c(0, 60), ylim = c(0, 10), col.regions = "lightgreen",
  col.point = c("red", "blue")
)
#> Error in eval(substitute(wireframe(x = x, data = data, groups = groups,     pch = pch, col.point = col.point, scales = scales, colorkey = colorkey,     screen = screen, panel = panel.disparity, aspect = aspect,     drape = drape, col.regions = col.regions, alpha.regions = alpha.regions,     perspective = perspective, R.mat = R.mat, par.settings = par.settings,     lattice.options = lattice.options, ...))): object 'g' not found
